尺寸
最大高度4281mm
最低位置-1700mm
最大臂展3253 mm
底座长宽950*919mm
底座高度610mm
有效运动范围79.86m³
'/%3e%3cpath%20d='M550.68,115.88l42.78-50h34.66L567.87,136.1l59.86,69.82H593.26l-42.58-49.61L508.3,205.92H473.73L533.5,136.1l-60-70.22h34.38Z'%20transform='translate(0.11%200)'/%3e%3cpath%20d='M770.7,91.27h-56V205.92h-25.4V91.27H633.3V65.88H770.7Z'%20transform='translate(0.11%200)'/%3e%3c/svg%3e)
U-MOCO EXT 影视摄影机械臂
极限臂展，拓宽视界新边界
01超宽6米翼展，释放更多创作空间
024米高峰，轻松捕捉高位视角
03从特写到远景，一台设备全搞定
04轨道加持，运镜范围无限延展
技术规格
核心尺寸、运动性能与使用环境
轴限位
A1±185°
A2-175°～+60°
A3-120°～+170°
A4±350°
A5±130°
A6±350°
性能
最大旋转线速度9.5 m/s
稳定速度2 m/s
最大直线速度4 m/s
额定负载20 kg
整机重量（依配置）≈958 kg
重复定位精度±0.05 mm
电力与环境
输入电源380 V
输入电流20 A
臂体防水等级IP65
运行温度0–55 °C
标尺示意图
