尺寸
最大高度2408 mm
最低位置−390 mm
最大臂展1540 mm
底座长宽780*750mm
底座高度610mm
最大运动范围3180mm
'/%3e%3cpath%20d='M557.71,209H532.32V69h25.39Z'%20transform='translate(0.11%200)'/%3e%3cpath%20d='M727.34,198.2a12.4,12.4,0,0,1-1,5.08,13,13,0,0,1-2.73,4.05,12.42,12.42,0,0,1-4.05,2.69,12.89,12.89,0,0,1-5,1,13.77,13.77,0,0,1-4.74-.88,11.05,11.05,0,0,1-4.25-2.84l-92.77-96.87V209H587.4V79.84a12.2,12.2,0,0,1,2.19-7.08A13.67,13.67,0,0,1,595.21,68a12.83,12.83,0,0,1,7.42-.73,12,12,0,0,1,6.54,3.56L702,167.64V69h25.39Z'%20transform='translate(0.11%200)'/%3e%3cpath%20d='M782.42,209H757V69h25.39Z'%20transform='translate(0.11%200)'/%3e%3c/svg%3e)
U-MOCO MINI 影视摄影机械臂
随心所欲，创意无阻
01小巧强悍，专为创意空间打造
02220V供电，拍摄无忧
03快速运镜，表现力十足
04人物产品，创作尽情挥洒
技术规格
核心尺寸、运动性能与使用环境
轴限位
A1±170°
A2-185°～+65°
A3-137°～+163°
A4±185°
A5±120°
A6±350°
性能
最大旋转线速度4.3 m/s
稳定速度2 m/s
最大直线速度3 m/s
额定负载10 kg
整机重量（依配置）≈412 kg
重复定位精度±0.04 mm
电力与环境
输入电源220 V
输入电流10 A
臂体防水等级IP65
运行温度0–55 °C
标尺示意图
